Welcome to Junaid Metals, your trusted partner in Manama, Bahrain, for premier industrial materials. We specialize in providing high-performance Titanium Grade 11 Bars and Rods, engineered to meet the most demanding applications. Known for its superior workability and exceptional corrosion resistance, this specific grade of titanium is an ideal choice for challenging environments. Our commitment is to deliver not just a product, but a reliable solution backed by expert local knowledge and a dedication to supporting the growth of industries across the region and beyond.
Titanium Grade 11 is a unique alloy distinguished by a small but crucial addition of palladium to the standard commercially pure titanium composition. This alteration significantly enhances its corrosion resistance, particularly against reducing acids and crevice corrosion. While maintaining the excellent formability and weldability of pure titanium, its mechanical properties include high ductility and a typical tensile strength around 240 MPa. This combination of traits makes it exceptionally durable and easy to fabricate for complex components, ensuring long-term reliability.
| Standards : | ASTM B348, B863 / ASME SB348, SB863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 11 | 3.7225 | R52250 |
| Grade | C | Fe | N | Ti | H | O |
| Titanium Gr. 11 | 0.08 max | 0.20 max | 0.03 max | Balance | 0.015 max | 0.18 max |
| Density | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.163 lb/in3, (4.51 g/cm3) | 240 | 170 | 24 % |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
|---|---|---|---|---|---|---|---|---|
| Titanium Gr 11 | .08 max | .03 max | .25 max | .015 max | Bal | 0.30 max | – | .12 – .25 |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@junaidmetals.com
Common titanium grades for bar manufacturing include Grade 1, Grade 2, Grade 5 (Ti-6Al-4V), Grade 7, Grade 9, Grade 11, and Grade 12, each offering unique strength and corrosion resistance.
The enhanced corrosion resistance of Titanium Grade 11 Bars and Rods makes them indispensable in critical chemical processing equipment, such as heat exchangers, reactors, and piping systems that handle harsh chlorides and acids. They are also widely used in marine and offshore applications for components exposed to seawater. In the pharmaceutical and biomedical fields, this grade is favored for its biocompatibility, often being used in implantable devices and surgical instruments. Essentially, wherever extreme corrosion is a primary concern, this material provides a robust and cost-effective solution.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Junaid Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manama, Bahrain
