Welcome to Junaid Metals, your trusted partner in Manama, Bahrain, for premium stainless steel solutions. We specialize in providing high-quality Stainless Steel 17-4 PH Hex Bars and Rods, engineered to meet the demanding needs of various industries. Our commitment is to supply materials that combine exceptional strength with superior corrosion resistance, ensuring your projects are built on a foundation of reliability and durability. When you choose Junaid Metals, you’re choosing a local source dedicated to supporting Bahrain’s industrial growth with products you can count on.
The composition of 17-4 PH Stainless Steel is a precise balance of chromium, nickel, and copper, with additions of niobium for stability. This unique mix allows it to be heat-treated to achieve impressive mechanical properties. After this treatment, it develops remarkable strength and hardness, rivaling that of many higher-strength steels, while still maintaining good toughness. Its most valued characteristic is its ability to resist corrosion in a wide range of environments, making it a versatile and high-performance material for critical components.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 17-4 PH | 0.07 max | 0.15-0.45 max | 15.00-17.50 max | 3.00-5.00 max | Bal | 1.0 | 3.0-5.0 | 0.40 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 17-4 PH | 170000 psi | 140000 psi | 6% | 38 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 17-4 PH | 1.4542 | S17400 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 17-4 PH Hex Bar and Rod should be stored in a dry, clean environment, away from moisture and corrosive substances. Ensure proper ventilation and avoid direct contact with chemicals or humidity.
Yes, Stainless Steel 17-4 PH Hex Bar and Rod can be used for structural applications due to its high strength, excellent corrosion resistance, and ability to withstand extreme environments, making it ideal for demanding conditions.
Common challenges when using Stainless Steel 17-4 PH Hex Bar include difficulties in machining due to its hardness, sensitivity to stress corrosion cracking in certain environments, and the need for precise heat treatment for optimal properties.
The unique strength and corrosion resistance of our 17-4 PH Hex Bars and Rods make them ideal for a wide array of challenging applications. You’ll find them essential in the aerospace industry for turbine parts, in oil and gas for valve components and pump shafts, and in the medical field for surgical instruments. They are also perfectly suited for creating durable fasteners, gears, and machining parts for the chemical and food processing industries. Essentially, wherever a combination of high strength and resistance to harsh conditions is needed, this material delivers outstanding performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
