Nestled in the heart of Manama’s industrial landscape, Junaid Metals stands as your trusted partner for high-performance alloys. We take pride in supplying top-tier Inconel 686 bars and rods, materials engineered to withstand the most punishing environments. Our dedication ensures that clients across critical sectors receive products that deliver unwavering reliability and exceptional longevity, backed by our deep understanding of the unique demands of your projects.
At its core, Inconel 686 is a nickel-chromium-molybdenum alloy fortified with tungsten, creating a remarkable resistance to a vast range of corrosive media, including harsh oxidizing and reducing acids. This carefully balanced composition grants it outstanding tensile strength and impressive creep resistance, even when subjected to the intense heat of elevated temperatures, making it a truly robust material.
| Element | Content (%) |
|---|---|
| Nickel, Ni | 59 |
| Chromium, Cr | 19-23 |
| Molybdenum, Mo | 15-17 |
| Iron, Fe | ≤ 5 |
| Tungsten, W | 3.0-4.40 |
| Manganese, Mn | ≤ 0.75 |
| Phosphorous, P | ≤ 0.040 |
| Sulfur, S | ≤ 0.020 |
| Titanium, Ti | 0.020-0.25 |
| Carbon, C | ≤ 0.010 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 721.9 MPa | 104700 psi |
| Yield strength (@strain 0.200%) | 364 MPa | 52800 psi |
| Elastic modulus | 207 GPa | 30000 ksi |
| Shear modulus | 77 GPa | 11200 ksi |
| Poisson’s ratio | 0.34 | 0.34 |
| Elongation at break | 71% | 71% |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 721.9 MPa | 104700 psi |
| Yield strength (@strain 0.200%) | 364 MPa | 52800 psi |
| Elastic modulus | 207 GPa | 30000 ksi |
| Shear modulus | 77 GPa | 11200 ksi |
| Poisson’s ratio | 0.34 | 0.34 |
| Elongation at break | 71% | 71% |
| Properties | Metric | Imperial |
|---|---|---|
| Thermal expansion co-efficient (@21-100°C/69.8-212°F) | 11.97 µm/m°C | 6.650 µin/in°F |
Yes, Inconel 686 Bars/Rods are designed to perform exceptionally well in high-temperature environments up to 980°C.
Yes, Inconel 686 bars/rods are weldable using standard techniques, but preheating and specialized filler materials are recommended to ensure strong, corrosion-resistant welds.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@junaidmetals.com
The exceptional durability of Inconel 686 bars and rods makes them indispensable in fields where failure is not an option. You’ll find them forming the backbone of chemical processing equipment, crucial components in pollution control scrubbers, and within the demanding environments of flue gas desulfurization systems. They are also vital in marine engineering for pulp and paper production, ensuring smooth operation where lesser materials would quickly succumb.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
