Nestled in the industrial heart of Manama, Junaid Metals has built a reputation for precision and reliability, specializing in high-performance alloys that meet the most demanding challenges. Our expertise shines in the production of Hastelloy C276 forgings, where we combine advanced manufacturing techniques with stringent quality control. We understand that behind every component is a critical application, which is why we are committed to delivering forged solutions that offer exceptional strength and longevity, ensuring your projects in Bahrain and beyond are built on a foundation of unwavering quality and trust.
The exceptional resilience of Hastelloy C276 forgings stems from a sophisticated nickel-molybdenum-chromium composition, carefully balanced with tungsten to create a formidable barrier against corrosion. This specific chemistry is expertly managed during our forging process, which enhances the material’s inherent strength, resulting in outstanding mechanical properties. The final product boasts a high tensile strength and excellent yield strength, allowing it to maintain structural integrity under extreme pressure and stress, making it a robust choice for the most punishing industrial environments.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Hastelloy C276 Forging UNS (N10276), DIN (2.4819)
ISO 9725
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Hastelloy C276 | Balance | 0.01 max | 15–17 | 1.0 max | 0.08 max | 4–7 | 0.04 max | 0.03 max | 2.5 max | 14.5–16.5 | 3–4.5 | 0.35 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
Post-forging operations for Hastelloy C276 include heat treatment (such as annealing) to relieve stresses and improve mechanical properties, followed by surface finishing (like pickling or grinding) to remove oxides and enhance corrosion resistance.
To determine if Hastelloy C276 forgings meet your needs, assess their chemical composition, mechanical properties, and resistance to corrosion under the specific conditions of your application. Conduct testing such as tensile, impact, and corrosion tests for confirmation.
The ideal temperature range for forging Hastelloy C276 is between 1,900°F and 2,200°F (1,038°C to 1,204°C). This ensures proper deformation without compromising material properties.
The true value of Hastelloy C276 forgings is realized in the field, where their resistance to a wide spectrum of corrosive agents is paramount. You will find these robust components hard at work within chemical processing reactors, critical pollution control scrubbers, and the demanding piping systems of oil and gas extraction. Their reliability is also crucial in pharmaceutical manufacturing and pulp and paper production, effectively handling harsh acids and chlorides. Essentially, wherever severe corrosion threatens equipment life and safety, these forgings provide a durable, long-lasting solution that minimizes downtime and ensures operational continuity.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Junaid Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manama, Bahrain
