Nestled in the heart of Manama’s bustling industrial scene, Junaid Metals has built a strong reputation as a trusted partner for quality materials. We take pride in our role as a leading supplier, particularly of the versatile Aluminium 5754 Bar and Rods. Our commitment is to provide our clients across Bahrain and beyond with products that combine exceptional strength with excellent workability, ensuring their projects are built on a foundation of reliability and superior performance that stands the test of time.
At its core, the strength of the 5754 grade lies in its magnesium-based composition, which gives it a robust character. This alloy is specially formulated to offer remarkable resistance to corrosion, making it a steadfast choice for challenging environments, especially where saltwater is a factor. It delivers a great balance of medium strength and excellent formability, meaning it can be readily shaped and welded without compromising its inherent durability, which is a key reason for its widespread trust.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Mg | Mn | Si | Cu | Fe | Cr | Zn | Ti | Cu | Other (Each) | Others (Total) | Al |
| 2.60 – 3.60 | 0.0 – 0.50 | 0.0 – 0.40 | 0.0 – 0.40 | 0.0 – 0.30 | 0.0 – 0.20 | 0.0 – 0.15 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.05 | 0.0 – 0.15 | Balance |
| Proof Stress | Tensile Strength | Elongation at 50 mm | Hardness Brinell |
| 80 Min MPa | 190 – 260MPa | 12 Min % | 52 HB |
| UNS | EN | DIN | ISO | USA | WNR |
| A95754 | EN AW-5754 | AlMg3 | AlMg3 | AA5754 | 3.3535 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 5754 bars and rods are suitable for structural applications due to their excellent strength, corrosion resistance, and formability, making them ideal for use in marine, automotive, and architectural structures.
Yes, Aluminium 5754 bars can be welded using various techniques, such as MIG and TIG welding. However, proper welding procedures and equipment are essential to maintain its strength and integrity.
Aluminium 5754 bars are typically sized based on diameter and length. The diameter can range from a few millimeters to several inches, while the length is often available in standard lengths, typically up to 6 meters. Custom sizes can also be ordered based on specific requirements. The bars are available in various shapes, including round, square, and hexagonal, to suit different applications.
You’ll find Aluminium 5754 Bar and Rods hard at work in some of the most demanding applications, particularly in the marine industry for boat fittings and offshore structures where its saltwater resistance is invaluable. It’s also a fundamental component in vehicle bodies, architectural panels, and various pressure vessels. Its excellent weldability and strength make it the go-to material for fabricating everything from sturdy storage tanks to intricate architectural details, proving its versatility across countless engineering and construction projects.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
