For over six decades, Junaid Metals in the heart of Manama has been a cornerstone of the region’s industrial supply, building a reputation for unwavering quality and reliability. We take immense pride in expanding our offerings to include high-precision Aluminium 2014 Forgings. This specific alloy is engineered for demanding applications where exceptional performance is non-negotiable, and our team is committed to delivering components that meet the most stringent specifications, directly supporting the growth and innovation of industries across Bahrain and beyond.
Crafted from an aluminum-copper alloy, the 2014 grade is distinguished by its remarkable strength, which is achieved through a controlled heat-treatment process. This results in a material with an excellent strength-to-weight ratio, making it significantly tougher than many other aluminum alloys. It also maintains good machinability, allowing for precise fabrication, and offers decent resistance to wear. These combined properties make it a preferred choice for components that must withstand high stress and rigorous operating conditions without failing.
Standards : ASTM B247, B247
Temper : T6 T651 T6511
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Aluminium 2014 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.7 | 0.50 – 1.20 | 0.2 – 0.8 | 0.4 – 1.2 | 3.9 – 5.0 | 0.25 | 0.15 | 93.5 |
| Material | Temper | Diameter (mm) | Tensile Strength min ((N/mm²) | Yield Strength (min) (N/mm²) | Elongation on 5.65 V (min) |
| 2014 Bar | T4 | <20 | 370 | 230 | 11 |
| 2014 Bar | T4 | 20-75 | 390 | 250 | 11 |
| 2014 Bar | T4 | 75-150 | 390 | 250 | 9 |
| 2014 Bar | T4 | 150-200 | 370 | 230 | 8 |
| 2014 Bar | T6510 | 20-75 | 480 | 435 | 7 |
| 2014 Bar | T6510 | 75-150 | 465 | 420 | 7 |
| 2014 Bar | T6510 | 150-200 | 435 | 390 | 7 |
| STANDARD | UNS | WERKSTOFF NR. | European Standard | BS (OLD) | ISO | USA (AA) | GERMANY (DIN) | IS | Canadian |
| Aluminium 2014 | A92014 | 3.1255 | EN AW-2014 | HE15 | AlCu4SiMg | 2014 | AlCuSiMn | 24345 | B26S |
Yes, Aluminum 2014 is suitable for high-temperature forging applications due to its excellent strength, thermal resistance, and good machinability, making it ideal for aerospace and automotive components.
Aluminum 2014 offers high strength, excellent machinability, good wear resistance, and superior performance under high-stress conditions, making it ideal for aerospace, automotive, and structural custom forgings.
The unique properties of Aluminium 2014 Forgings make them indispensable in fields where failure is not an option. You will find these robust components forming the backbone of critical aerospace structures like aircraft landing gear and internal fuselage frames. They are equally vital in the transportation sector for heavy-duty truck frames and suspension parts. Beyond that, they are essential in high-performance machinery, used for everything from robust pistons and hydraulic components to durable robotics and tools that face constant, heavy use.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Junaid Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manama, Bahrain
